Recovering Data From An Old Encrypted Time Machine Backup

Recovering data from a backup should be an easy thing to do. At least this is what you expect. Yesterday I had a problem which should have been easy to solve, but it was not. I hope this blog post can help others who face the same problem.

The problem

1. I had an encrypted Time Machine backup which was not used for months
2. This backup was not on an official Apple Time Capsule or on a USB HDD, but on a WD MyCloud NAS
3. I needed files from this backup
4. After running out of time I only had SSH access to the macOS, no GUI

The struggle

By default, Time Machine is one of the best and easiest backup solution I have seen. As long as you stick to the default use case, where you have one active backup disk, life is pink and happy. But this was not my case.

As always, I started to Google what shall I do. One of the first options recommended that I add the backup disk to Time Machine, and it will automagically show the backup snapshots from the old backup. Instead of this, it did not show the old snapshots but started to create a new backup. Panic button has been pressed, backup canceled, back to Google.

Other tutorials recommend to click on the Time Machine icon and pressing alt (Option) key, where I can choose "Browse other backup disks". But this did not list the old Time Machine backup. It did list the backup when selecting disks in Time Machine preferences, but I already tried and failed that way.

YAT (yet another tutorial) recommended to SSH into the NAS, and browse the backup disk, as it is just a simple directory where I can see all the files. But all the files inside where just a bunch of nonsense, no real directory structure.

YAT (yet another tutorial) recommended that I can just easily browse the content of the backup from the Finder by double-clicking on the sparse bundle file. After clicking on it, I can see the disk image on the left part of the Finder, attached as a new disk.
Well, this is true, but because of some bug, when you connect to the Time Capsule, you don't see the sparse bundle file. And I got inconsistent results, for the WD NAS, double-clicking on the sparse bundle did nothing. For the Time Capsule, it did work.
At this point, I had to leave the location where the backup was present, and I only had remote SSH access. You know, if you can't solve a problem, let's complicate things by restrict yourself in solutions.

Finally, I tried to check out some data forensics blogs, and besides some expensive tools, I could find the solution.

The solution

Finally, a blog post provided the real solution - hdiutil.
The best part of hdiutil is that you can provide the read-only flag to it. This can be very awesome when it comes to forensics acquisition.

To mount any NAS via SMB:

mount_smbfs afp://<username>@<NAS_IP>/<Share_for_backup> /<mountpoint>

To mount a Time Capsule share via AFP:

mount_afp afp://any_username:password@<Time_Capsule_IP>/<Share_for_backup> /<mountpoint>

And finally this command should do the job:

hdiutil attach test.sparsebundle -readonly

It is nice that you can provide read-only parameter.

If the backup was encrypted and you don't want to provide the password in a password prompt, use the following:

printf '%s' 'CorrectHorseBatteryStaple' | hdiutil attach test.sparsebundle -stdinpass -readonly

Note: if you receive the error "resource temporarily unavailable", probably another machine is backing up to the device

And now, you can find your backup disk under /Volumes. Happy restoring!

Probably it would have been quicker to either enable the remote GUI, or to physically travel to the system and login locally, but that would spoil the fun.

How SSPM Simplifies Your SOC2 SaaS Security Posture Audit

An accountant and a security expert walk into a bar… SOC2 is no joke.

Whether you're a publicly held or private company, you are probably considering going through a Service Organization Controls (SOC) audit. For publicly held companies, these reports are required by the Securities and Exchange Commission (SEC) and executed by a Certified Public Accountant (CPA). However, customers often ask for SOC2 reports as part of their vendor due diligence process.

Out of the three types of SOC reports, SOC2 is the standard to successfully pass regulatory requirements and signals high security and resilience within the organization — and is based on the American Institute of Certified Public Accountants (AICPA) attestation requirements. The purpose of this report is to evaluate an organization's information systems relevant to security, availability, processing integrity, confidentiality, and privacy — over a period of time (roughly six to twelve months).

As part of a SOC2 audit, it is necessary to conduct security checks across the company's SaaS stack that will look for misconfigured settings such as detection and monitoring to ensure continued effectiveness of information security controls and prevent unauthorized/ inappropriate access to physical and digital assets and locations.

If you're beginning or on a SOC2 audit journey, then an SSPM (SaaS Security Posture Management) solution can streamline the process and shorten the time it takes to pass a SOC2 audit successfully, fully covering your SaaS Security posture.

Learn how to streamline your organization's SOC2 compliance

What are the AICPA Trust Services Criteria (TSC)?

When external auditors engage in a SOC 2 audit, they need to compare what you're doing to a long list of established requirements from AICPA TSC. The "Common Controls" fall into five groups:

Security - Includes sub controls of the Logical and Physical Access (CC6)
Availability - Includes sub controls of the System Operations (CC7)

Processing integrity: Includes sub controls of the System Operations (CC7)
Confidentiality: Includes sub controls of the Logical and Physical Access (CC6)
Privacy - Includes sub controls of the Monitoring Activities (CC4)

Within each common control are a set of sub controls that turn the overarching standard into actionable tasks.

Passing a SOC 2 audit takes a lot of time, effort, and documentation. During a SOC2 audit, you not only need to show that your controls work during the audit period, but you also need to show that you have the ability to continuously monitor your security.

Going through the entire TSC framework is too long for a blog post. However, a quick look into a couple of controls of Logical and Physical Access (CC6) and System Operations (CC7) gives you an idea of what some of the controls look like and how you can utilize an SSPM to ease the SOC2 audit.

Get a 15-minute demo of how an SSPM can help your SOC 2 TSC audit

Logical and Physical Access Controls

This section sets out the types of controls needed to prevent unauthorized or inappropriate access to physical and digital assets and locations. Managing user access permissions, authentication, and authorization across the SaaS estate poses many challenges. In fact, as you look to secure your cloud apps, the distributed nature of users and managing the different access policies becomes increasingly challenging.

Under CC6.1 control, entities need to:

Identify, classify, and manage information assets
Restrict & manage user access
Consider network segmentation
Register, authorize, and document new infrastructure
Supplement security by encrypting data-at-rest
Protect encryption keys

Example

The department that utilizes a SaaS app is often the one that purchases and implements it. Marketing might implement a SaaS solution for monitoring leads while sales implements the CRM. Meanwhile, each application has its own set of access capabilities and configurations. However, these SaaS owners may not be trained in security or able to continuously monitor the app's security settings so the security team loses visibility. At the same time, the security team may not know the inner workings of the SaaS like the owner so they may not understand more complex cases which could lead to a security breach.

An SSPM solution, maps out all the user permissions, encryption, certificates and all security configurations available for each SaaS app. In addition to the visibility, the SSPM solution helps correct any misconfiguration in these areas, taking into consideration each SaaS app's unique features and usability.

In CC.6.2 control, entities need to:

Create asset access credentiations based on authorization from the system's asset owner or authorized custodian
Establish processes for removing credential access when the user no longer requires access
Periodically review access for unnecessary and inappropriate individuals with credentials

Example

Permission drifts occur when a user has certain permissions as part of a group membership, but then gets assigned a specific permission that is more privileged than what the group has. Over time many users get extra permissions. This undermines the idea of provisioning using groups.

Classic deprovisioning issues, an SSPM solution can spot inactive users and help organizations to quickly remediate, or at the very least, alert the security team to the issue.

Under CC.6.3 control, entities need to:

Establish processes for creating, modifying or removing access to protected information and assets
Use role-based access controls (RBAC)
Periodically review access roles and access rules

Example

You might be managing 50,000 users across five SaaS applications, meaning the security team needs to manage a total of 250,000 identities. Meanwhile, each SaaS has a different way to define identities, view them, and secure identities. Adding to the risk, SaaS applications don't always integrate with each other which means users can find themselves with different privileges across different systems. This then leads to unnecessary privileges that can create a potential security risk.

An SSPM solution allows visibility into user privileges and sensitive permission across all connected SaaS apps, highlighting the deviation from permission groups and profiles.

System Operations

This section focuses on detection and monitoring to ensure continued effectiveness of information security controls across systems and networks, including SaaS apps. The diversity of SaaS apps and potential for misconfigurations makes meeting these requirements challenging.

In CC7.1 control, entities need to:

Define configuration standards
Monitor infrastructure and software for noncompliance with standards
Establish change-detection mechanisms to aler personnel to unauthorized modification for critical system, configuration, or content files
Establish procedures for detecting the introduction of known or unknown components
Conduct periodic vulnerability scans to detect potential vulnerabilities or misconfigurations

It is unrealistic to expect from the security team to define a "configuration standard" that complies with SOC2 without comparing against a built-in knowledge base of all relevant SaaS misconfigurations and to continuously comply with SOC2 without using an SSPM solution.

Get a 15-minute demo to see how an SSPM solution automates your SaaS security posture for SOC2 and other standards.

Read more

BYOPPP - Build Your Own Privacy Protection Proxy

I have read a blog post, where you can build your own privacy proxy server built on Raspberry PI. The post got me thinking about how I can use this to protect my privacy on my Android phone, and also get rid of those annoying ads.

Since I own a Samsung Galaxy S3 LTE with Android 4.3 (with a HW based Knox counter), rooting the phone now means you break Knox, and loose warranty. Past the point of no return ...

This means I have to solve this without root. Luckily newer Androids support VPN without rooting, but setting a mandatory system-wide proxy is still not possible without root.

But thanks to some iptables magic and Privoxy, this is not a problem anymore :)

The ingredients to build your own privacy protection proxy:

One (or more) cheap VPS server(s)
a decent VPN program
Privoxy
iptables

VPS server

To get the cheap VPS server, I recommend using Amazon EC2, but choose whatever you like. The micro instance is very cheap (or even free), and has totally enough resources for this task. I'm using the Ubuntu free tier now and it works like a charm. And last but not least Amazon has two-factor authentication! You can set up an Ubuntu server under 10 minutes. Use the AWS region nearest to you, e.g. I choose EU - Ireland.

VPN

For the VPN program, I recommend the free version of the OpenVPN AS (EDIT: be sure to use OpenVPN AS 2.0.6 or later, both on the server and the client). Easy to set-up quick start guide is here, GUI based configuration, and one-click client installer for Android, iOS, Windows, Linux, OSX. The Ubuntu installer packages are here.

The most important settings:

I prefer to use the TCP 443 and UDP 53 ports for my OpenVPN setup, and let the user guess why.
For good performance, UDP is preferred over TCP.
VPN mode is Layer 3 (routing/NAT).
Don't forget to allow the configured VPN ports in the AWS firewall (security groups).

Other VPN settings:

Should VPN clients have access to private subnets (non-public networks on the server side)? - Yes
Should client Internet traffic be routed through the VPN? - Yes

Privoxy

The next component we have to install and configure is Privoxy. As usual, "apt-get install privoxy" just works. The next step is to configure privoxy via /etc/privoxy/config file, there are two options to change:

listen-address your.ip.add.ress:8118
accept-intercepted-requests 1

Beware not to allow everyone accessing your Privoxy server in the AWS EC2 security groups, be sure it is reachable only to VPN users!

After everything is set, start privoxy with "service privoxy start", and add it to the autostart "update-rc.d privoxy defaults".

Iptables

And the final step is to configure your iptables chain to forward every web traffic from the VPN clients to the Privoxy server:

iptables -t nat -A PREROUTING -s 5.5.0.0/16 -p tcp -m multiport --dports 80,8080,81 -j DNAT --to-destination your.ip.add.ress:8118

Optionally you can block access to all other ports as well, and what does not go through your Privoxy won't be reachable.

Based on your Linux distribution and preference, you might make this rule persistent.

Final test

Now you can connect to the VPN server from your Android device.

After logging in from a client, you get the following nice packages to install on your device:

After connecting, the final results can be seen in the following screenshots. And yes, there is a reason I chose Angry Birds as an example.

Angry Birds without Privoxy

Angry Birds with Privoxy

Stupid flashlight app with ad

Stupid flashlight app with Privoxy

Spoiler alert

If you are afraid of NSA tracking you, this post is not for you. If you want to achieve IP layer anonymity, this post is not for you. As long as you are the only one using that service, it should be trivial to see what could possibly go wrong with that.

Known issues

Whenever the Internet connection (Wifi, 3G) drops, the VPN connection drops as well, and your privacy is gone ...

Sites breaking your privacy through SSL can still do that as long as the domain is not in the Privoxy blacklist.

Additional recommendation

If you are using OSX or Windows, I can recommend Aviator to be used as your default browser. It is just great, give it a try!

PS: There are also some adblock apps removed from the official store which can block some ads, but you have to configure a proxy for every WiFi connection you use, and it is not working over 3G.
